Metal AM Solutions
Meltio Multi-laser DED Technology, the first wire based metal laser deposition (WMLD), allows us at ACCUFACTURE, to engineer turnkey Metal Additive Manufacturing robotic solutions for our customers.
This integration enables high-performance, affordable, and easy-to-use metal 3D printing, part repair, cladding, and feature addition.
Produce custom metal parts of 99.998% density in a single-step process!
NEW! Alchemist I
Alchemist I our premier, standard Robotic Additive Manufacturing cell designed specifically for metal fabrication. WLMD technology with 8-axis of freedom and a generous build volume, Alchemist I enables the fabrication of large intricate geometries.
Specs:
​
Print Envelope (DxH): ø1400mm x 1200mm
​
Laser Type: 6 x 200 W direct diode lasers
​
Laser Wavelength: 976 nm
​
Enclosure: Class I Laser-safe, with optional air extraction
​
Motion Tech: Slicer and motion software included
Meltio M600 3D Printer
The new Meltio industrial metal printer!
More capabilities with blue lasers, a larger build volume, and a fully inert chamber for the best material properties. The improved process control, advanced sensors and live monitoring allowing you to produce parts consistently 24/7.
​
Specs:
​
Print Envelope (WxDxH): 300 x 400 x 600 mm
​
Laser Type: 9x Direct Diode Lasers
​
Laser Wavelength: 450 nm (Blue)
​
Total Laser Power: 1000 W
​
Touch Probe: Automated XYZ Touch Probe integrated
​
Enclosure: Laser-safe, controlled inert atmosphere
Custom Metal AM Integration
Turn a robot arm into a metal 3D printing system with no inherent size constraints. Our custom robotic AM cells, powered by the Meltio robot engine, are the perfect platform for large and complex 3D printing, repair, cladding, and feature addition.
Specs:
​
Print Envelope (WxDxH): Depending on the integration
​
Laser Type: 6 x 200 W direct diode lasers
​
Laser Wavelength: 976 nm
​
Total Laser Power: 1200 W
​
Enclosure: Laser-safe, based on customer requirements
Meltio M450 3D Printer
Designed for manufacturing without the need for industrial infrastructure; affordable, reliable, safe and easy to use metal 3D printer. Ideal for small to medium size shops to help increase capabilities and reduce machine time.
Specs:
​
Print Envelope (WxDxH): 145 x 168 x 390 mm
​
Laser Type: 6 x 200 W direct diode lasers
​
Laser Wavelength: 976 nm
​
Total Laser Power: 1200 W
​
Enclosure: Laser-safe, sealed, controlled atmosphere
Open Materials Platform
Titanium
Highest strength to weight ratio and corrosion resistance
Mild Steel
Cheap and ductile, with unparalleled machinability and weldability
Nickel
High versatility, outstanding heat and corrosion resistance
Carbon Steel
High impact strength, retain hardness at high temperatures
Copper
Under development
Stainless Steel
Excellent strength and corrosion
resistance
Upgrades and Accessories
Hot Wire
Programmable power supply that preheats the material to increase the deposition rate.
Laser Calibration System
It allows users to calibrate Meltio’s multi-laser deposition head accurately and effortlessly prior to every print.
Dual Wire
This option allows to 3D print two wire materials sequentially with very quick wire switches.
Station
Sturdy wheeled table made from stainless steel and aluminum. Contains tool and material drawers.
Reliable
The metal 3D printing process is monitored in real time and compensated if required by process control.
Easy to Use
Automatic toolpath generation and material print profiles supplied by Meltio make for a plug and play experience.
Affordable
The low capital and running costs of the Meltio M450 make metal 3D printing of conventional parts possible. Cost-effective component repair, part augmentation, and feature addition.
Retrofitting
Provide new capability to any robot arm by turning it into a metal 3D printing system.
